接收端與發射端之間的CAT5e或者CAT6線纜長度 ..............................可達60米
HDMI 輸入 ................................. 1080p/1080i/720p/576p/576i/480p/480i
HDMI 輸出 ................................. 1080p/1080i/720p/576p/576i/480p/480i
最大傳輸帶寬 .............................................................150MHz
最大傳輸速率 ........................................................... 4.5Gbps
輸入視頻信號 ...................................................0.5~1.5Volts p-p
輸出DDC 信號 ...................................................5Volts p-p (TTL)
輸入HDMI線纜長度 .................................≤10m AWG26 標準HDMI規格的線纜
輸出HDMI線纜長度 .................................≤15m AWG26 標準HDMI規格的線纜
最大工作電流TX ............................................................300mA
最大工作電流RX ............................................................300mA
工作溫度范圍 .....................................................(-15 至 +45℃)
工作濕度范圍 ................................................5 to 90%RH (無冷凝)
尺寸 (長 x 寬 x 高) ............................................... 52x38x17(mm)
TX重量 ....................................................................24.5g
RX重量 ....................................................................24.9g
